Description

Burnt Titanium PLA



The Eryone Burnt Titanium PLA filament is a material that exhibits captivating color
changes under different lighting and angles, creating a unique technological atmosphere and
providing an exceptional visual and tactile experience. This material has excellent toughness, producing no bubbles or odors during the printing process, and is resistant to clogging or
warping, ensuring outstanding shaping results and a smoother printing experience. Additionally, its Z-axis tensile strength reaches 34 MPa, with excellent interlayer adhesion.

Part I:Suggests Printing Parameters

Parameter		Set up
Nozzle temperature		190-220 ℃
Bed temperature		55-70℃
Bed materia		glass, PEI, spring steel plate
Bottom printing temperature		190-220 ℃
Sealed printing		Supports open printing; better results with enclosure.
Printing speed		30-100mm s
Drying conditions		65-75℃, 12h



Part II: Physical Properties of Materials

Property		Testing Method		Unit		Typical Value
Density(g cm³ at 21.5 ° C）		ASTM D792 (ISO 1183, GB T 1033)		g cm³		1.23
Vicat Softening Temperature(° C)		ASTM D1525 (ISO 306 GB T 1633)		℃		54
Heat distortion temperature(° C)		ASTM D648 1.8MPa 0.45MPa		℃		53
Glass transition temperature (° C)		DSC, 10 ° C min		℃		62
Melt Index(g 10 min)		220 ° C, 10kg 240 ° C, 2.16 kg		g 10min		6



Part III: Mechanical Properties of Printed Samples

Property		Test conditions		Test standards		unit		Typical Value
Tensile strength X-Y		50mm min		GB T 1040.4		MPa		52.2
Elastic modulus X-Y		50mm min		GB T 1040.1-2006		MPa		1737.5
Elongation at break X-Y		50mm min		GB T 1040.4		%		2.1
Tensile strength X-Z		50mm min		GB T 1843		MPa		34.2
Elastic modulus X-Z		50mm min		GB T 1040.1-2006		MPa		1623.7
Elongation at break X-Z		50mm min		GB T 1040.4		%		1.9
Bending strength		2mm min		GB T 9341		MPa		82.4
Bending modulus		2mm min		GB T 9341		MPa		2861.7
Charpy Impact strenght		2.75J		GB T 1843		kJ m2		3.7



Note: All splines are printed under the following conditions: printing temperature=210 ° C, printing speed=80mm s, base plate 60° C, filling=100%, nozzle diameter=0.4mm

Additional information

SHIP TO	US (TO US ONLY), EU (TO EU ONLY), UK (TO UK ONLY), CA (TO CA ONLY)
Color	Green, Dark Gold, Red, Blue Purple, Blue, Technology Blue, Constellation (Rose Red & Flash Black), Interstellar (Blue & Flash Black), Wormhole (Green & Flashing Black), Galaxy (Green & Blue & Rose Red), Nebula (Dark Gold & Green & Blue-Purple)
